PA-500
耐熱性にすぐれた
準工業用機
準工業用機
ヒートシンクケース採用
長時間、高負荷のアプリに最適
耐熱性に優れたヒートシンクケース、高解像度映像の長時間再生や高負荷のアプリの使用に適しています。
設置環境のバリエーションに広く対応しております。

熱・振動に強いタフネス設計
ヒートシンクケース採用の準工業用STB
様々なシステムにおいてSTBの重要性が高くなる中、環境対応力も求められています。Cast Edge PA-500は、準工業設計のヒートシンクモデルです。熱・振動に強く、設置環境のバリエーションに広く対応しております。
Android9.0搭載 クアッドコア+デュアルコアプロセッサ搭載。
Point 1 IoTゲートウェイ
放熱性が高いヒートシンクケースを採用
筐体にヒートシンクケースを採用。
放熱性が高く熱に強い設計*になっています。


Point 2 中継端末
騒音・振動に耐えるタフネス設計
工業機器として設計デザインされているため、騒音や振動にも強さを発揮します。
Point 3 デジタルサイネージ
VESAマウンター付で取り付け便利
付属のVESAマウンターによりモニターへの取り付け作業が容易にできます。

PA-500本体

付属リモコン

Spec
ハードウェアスペック
- OS
- Android 9.0
- 言語
- 日本語、中国語、英語、その他、マルチ言語対応
- チップセット
- Amlogic S922X Quad core ARM Cortex-A73 1.7GHz and dual-core ARM Cortex-A53 1.8GHz
- GPU
- ARM Mali TM-G52 MP6(6ppc) up to 800MHZ
- 拡張ストレージ
- Support MicroSD(TF) card, Max to 32GB
- SDRAM
- DDR4 2GB (for OEM orders 3GB-4GB)
- Nand Flash
- 16GB (compatibility 8GB-32GB)
- Wi-Fi
- AmPack 6398S, 2.4GHz / 5.0GHz
IEEE 802.11 a/b/g/n/ac MIMO standard - GPS
- なし
- Ethernet
- 1 x RJ45 LAN Port 1000M (Gigabit network)
- Power Supply
- DC 12V/2A
インターフェース
- HDMI
- 1 x HDMI (A type Female, 2.1 and 2.0) 4K@60fps
- Bluetooth
- Bluetooth 5.0 with LE technology
- USB Port
- 1 × USB (3.0) , 3 × USB Host
- Data Output
- 1 x SPDIF
- Card Reader
- 1 x TF Card reader
- AV Out
- なし
- Network
- 1 x RJ45 LAN Port LAN with wake on LAN function
- Power Supply
- 1 x DC Jack
- Antenna
- External DualBand WiFi Antenna×2
諸パラメーター
- Operation Temperature
- ‘0~60℃
- Storage Temperature
- ‘-20~60℃
- Humidity Environment
- 5%-90%(No condensation)
- Certificate
- TELEC
パッケージ
- Dimension (mm)
- 115×116×34
- Net Weight
- 約 500g(本体重量)
- Box Size (mm)
- 160×150×90
- タッチドライバー
- なし
- 技適
- 取得済み
- 同梱品
- 本体・リモコン・AC アダプタ・HDMI コード(15cm)・説明書・保証書、× 各 1
拡張アンテナ ×2 - 注意事項
- USB からの供給電力で動作するバスパワーの周辺機器は、電力不足で正常動作しない場合があります。
対応コーデック
ビデオコーデック
- VP9 Profile-2 up to 4Kx2K@60fps H.265 HEVCMP-10@L5.1 up to 4K*2K @60fps
-
- H.264 AVC HP@L5.1 up to4K*2K@60fps
- H.264 MVC up to1080P@60fps
- MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)
- WMV/VC-1 5P/MP/AP up to 1080P@60fps
- AVS-P16(AVS+)/AVS-P2 jiZhun Profile up to 1080P@60fps
- MPEG-2 MP/HL up to 1080P@60fps(ISO-13818)
- MPEG-1 MP/HL up to 1080P@60fps(ISO-11172)
- Realvideo 8/9/10 up to 1080P
- WebM up to VGA
- Multiple language and multiple format sub-title video support
- MJPEG and JPEG unlimited pixe resolution decoding(ISO/IEC-109 18)
- Supports JPEG thumbnail, scaling, rotation and transition effe cts
- Support *.mkv,*.wmv,*.mpg,*.mpeg,*.dat,*.avi,*.mov,*.iso,*.mp 4,*.rm
- and *.jpg file formats
オーディオコーデック
- Audio Codec
-
- Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
I2S audio interface supporting 2-channel input and 8-channel (7 .1) output
Built-in serial digital audio SPDIF/IEC958 output and PCM input /output
Built-in stereo audio DAC,
Stereo digital microphone PDM input
Support concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM
- Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
オーディオアウト
- Audio Out
-
- HDMI data output, audio output and SPDIF
